BET Surface Area & Pore Size Analyzer

Quantachrome Autosorb iQ-MP Automated Gas Sorption Analyzer

Analysis capabilities & specifications:

Isotherms:

  • Multipoint and single point BET
  • Up to 1000 data points

Surface area range:

  •   0.01 m2/g to no known upper limit (nitrogen)
  •   0.0005 m2/g to no known upper limit (krypton)

Pore size range: 3.5 to >5000Ǻ / 0.35 to >500 nm

Pore volume (liquid)

Simultaneous operation: Analysis while degassing

P/P0 range: <1 x 10-7 to 0.999

  • Sensitivity: 1 x 10-9 ml/g (using 1 torr transducer)

Adsorbed volume (STP)​:

  • Sensitivity: 5 x 10-8 cc/g (using 1 torr transducer)

Temperature range: Ambient to 350 °C
